ASSIGNMENT 2
My Space
THE TASK
For our second assignment, we are required to choose a space in our own home and produce sets of technical drawing according to suitable scale. For this assignment, I chose to draw my living room space. After finalising on our spaces from our homes, we are required to produce a floor plan, two elevations (longitudinal and horizontal), section and also detailed drawings on a loose furniture that we can choose from our space. The drawings are required to be drawn using suitable common scales according to the size of our spaces.
MY PROGRESS
week 1 :
For the first week of this assignment, I took pictures of my living room and did a draft floor plan of the space. During tutorials, I got feedback from Sir Akmal and got the approval of my selected space so I can proceed with the rest of the drawings using 1:50 scale.
FINAL OUTCOME
REFLECTION
During this assignment, I had a few troubles in producing the set of drawings in the beginning. For example, I was having a hard time drawing the furnitures and also choosing the suitable scale because my living room space was quite large. However, after practicing and starting over my drawings, I was more comfortable once I got used to it. Not only that, guidance and feedback from Sir Akmal was also very helpful during this assignment. Because with every feedback i was able to produce a better drawing by improving them. To conclude, this assignment thought me to reach out when help is needed and to try again when I fail.
